VBG Multi XF Drawbar
VBG Multi XF is a lightweight yet strong drawbar, and fits trailers with c/c distances of between 700 mm – 1300 mm. Drawbar lengths vary between 1269 – 4358 mm, in increments of approx. 62 mm. It is very easy to mount using bolted joints, and, to further simplify installation, there is a special centring device which fits into the drawbar eye. Several options The drawbar can be fitted with either Vibra blocks or Bria brackets for attachment to the trailer. Five different drawbar eyes are available: VBG MFC, SS Ø57 mm, SS Ø57 mm angled 5°, ISO Ø50 mm and DIN Ø40 mm. SS Ø57 mm angled 5° is used when there is a low attachment point on the trailer. Accessories The drawbar can be supplied with a foot step, catwalk and balance spring, or the like, which adjusts the drawbar to the height of the coupling. VBG Multi XF Drawbar consists of 4 Side members 1 Eye 1-2 Cross members 2 Rear brackets with fitted Vibra blocks (Ø 32 mm) or Briab brackets 2 Pivot bolts or Briab installation kit 6 Cross member bolt kits 1-2 Cross member bolt kits
